The Ithaca 9000 printer can be purchased with several different communication interfaces. Please use the below chart to identify which interface your printer has:

9 pin Serial Interface
Cable Required: Serial Null Modem Cable, 9 pin female to 9 pin female.
This cable is available for purchase from us.
Item No: 10-2020

36 pin Centronics Parallel Interface
Cable Required: Parallel Cable, 25 pin male to 36 pin Centronics male.
This cable is available for purchase from us.
Item No: 253-9800002

USB Interface
Cable Required: USB Cable
This cable is available for purchase from us.
Item No: 98-04322

Ethernet Interface
Cable Required: CAT-5 Ethernet cable
This cable is not available for purchase from us.

25 pin Parallel Interface
Cable Required: Parallel Cable, 25 pin male to 25 pin male.
This cable is available for purchase from us.
Item No: 253-9800007

25 pin Serial Interface
Cable Required: Serial Null Modem Cable, 9 pin female to 25 pin male.
This cable is available for purchase from us.
Item No: 253-9800006

 Caution: The 25 pin Parallel and 25 pin Serial interfaces look exactly the same externally.


They both use a 25 pin D-shell connection. A closer look will reveal that the electronics on the actual interfaces boards are different. The best way to determine which 25 pin communication interface is present in the printer is to print a configuration listing from the printer. This listing will show either RS232 Serial or P1284 Parallel. See Manual Configuration for how to print out this listing.

Parallel and serial communications are two distinct ways of getting data from a PC to our printer. Serial communication transmits data on only 2 wires, one for sending and one for receiving one bit at a time. Parallel communication transmits data across multiple wires simultaneously. This provides a faster means of data transmission than serial. A parallel printer must be connected to a parallel port, commonly labeled as an LPT port on a PC. The LPT port should be set for bi-directional, standard, or SPP. A serial printer must be connected to a serial port, commonly labeled as a COM port on a PC. The COM port settings must match the printer serial settings to communicate properly. Please consult your PC’s literature to learn how to change these setting.

The Ithaca 9000 printer has an RJ11 cash drawer port for connecting a cash drawer. This port is hard wired for an EPSON configuration. When purchasing a cash drawer to use with this printer, an Epson cash drawer cable must be ordered. Cash drawer cables are not available from TransAct. Once you have the correct cable, you will still need to send the correct cash drawer command code to the printer to open the drawer. The cash drawer code depends on the Emulation Mode the printer is in. This can be determined by printing a configuration listing. See Manual Configuration for how to print out this listing. The follow are the codes for the common Emulation Modes:

Ithaca PCOS
Cash Drawer 1 | ASCII : [ESC] x 1 | DECIMAL: 27 120 1 | HEX: 1B 78 01
Cash Drawer 2 | ASCII : [ESC] x 2 | DECIMAL: 27 120 2 | HEX: 1B 78 02

EPSON
Cash Drawer 1 | ASCII : [ESC] p 0 | DECIMAL: 27 112 0 | HEX: 1B 70 00
Cash Drawer 2 | ASCII : [ESC] p 1 | DECIMAL: 27 112 1 | HEX: 1B 70 01

Star
Cash Drawer 1 | ASCII : [BEL] | DECIMAL: 7 | HEX: 07
Cash Drawer 2 | ASCII : [SUB] | DECIMAL: 26 | HEX: 1A

Microline
Cash Drawer 1 | ASCII : [BEL] | DECIMAL: 7 | HEX: 07
Cash Drawer 2 | ASCII : [BS] | DECIMAL: 8 | HEX: 08

The printer will cut the paper when the printer receives the cut command from the system. This command code depends on the Emulation Mode the printer is in. This can be determined by printing a configuration listing. See Manual Configuration for how to print out this listing. The follow are the codes for the common Emulation Modes:

Ithaca PCOS
Cut | ASCII: [ESC] v | DECIMAL: 27 118 | HEX: 1B 76

EPSON
Cut | ASCII: [ESC] i | DECIMAL: 27 105 | HEX: 1B 69

Star
Cut | ASCII: [ESC] d 0 | DECIMAL: 27 100 0 | HEX: 1B 64 00

Microline
Cut | ASCII: [EM] | DECIMAL: 25 | HEX: 19

The Ithaca 9000 printer is a thermal printer that requires thermal paper. Verify the paper you are using is thermal paper. Make sure the paper is loaded properly. To load paper, simple drop the paper roll into the printer with the paper coming from the bottom of the roll. Pull the paper out a little bit, and close the lid. Printer should cut the paper, and be ready to print. (No error LED, just solid Green LED) Verify you have selected the correct communication port on the system. If the printer has a serial port, make sure you are connected to the serial port of the PC with a serial null-Modem cable. Verify that the configuration settings of the printer are set to the correct Emulation Mode and communication settings for your system. See Manual Configuration for how to print out this listing.

The most common reason why this happens is because the "Enable bidirectional support" checkbox is checked under the Ports tab in the Properties of your printer. To uncheck this, go to your Printers and Faxes/Devices and Printers page, right click on your printer and select Properties/Printer Properties, click the Ports tab, uncheck the "Enable birdirectional support" checkbox, then click the Apply button, and then click the OK button.

The “Lang Mon” error is due to the driver's lack of privileges writing to the registry.

If you encounter this error, please use the “TransactPrinterProperties.exe” program found in the Utilities folder that comes with the Windows drivers.

Note:  You must Right Click the TransactPrinterProperties.exe program and select Run as administrator to allow the changes to be saved to the registry.

Change values as you want them, and then click the Save Changes button.

Then Select Yes to allow the Windows Print Spooler to be restarted for the change to take effect.
